Product Overview: SN74AVC4T774PW

The SN74AVC4T774PW is a versatile, high-speed, quadruple bit-level voltage translator device from Texas Instruments (TI), designed to address the needs of multi-voltage systems with bidirectional translation between different logic levels. It is a member of the AVC family, which is known for its low-voltage operation and high-speed interface technology.

Key Features

• Voltage Level Translation: The SN74AVC4T774PW is capable of translating signals between two different voltage domains, ranging from 1.2V to 3.6V on the A side and 1.65V to 5.5V on the B side, which is ideal for interfacing between low-voltage microprocessors or microcontrollers and higher voltage peripherals.
• High-Speed Data Transfer: It can support data rates up to 380 Mbps, making it suitable for high-speed data applications such as telecommunications, computing, and networking.
• Low Power Consumption: The device is designed for low power consumption, with a typical ICC of only 10 µA, minimizing power usage in battery-powered devices.
• Flow-Through Pinout: The SN74AVC4T774PW comes in a 16-pin TSSOP package with a flow-through pinout that simplifies PCB layout by allowing inputs to be directly connected to outputs on the opposing side of the board.

Applications

The SN74AVC4T774PW is suitable for a wide range of applications including:

• Mobile Phones
• PDAs
• Digital Cameras
• Notebook and Desktop Computers
• Data Communication Systems

Quality and Reliability

As with all Texas Instruments products, the SN74AVC4T774PW is manufactured to the highest quality standards. TI's commitment to quality ensures that the device is reliable and performs consistently in the most demanding environments.

Environmental Information

The SN74AVC4T774PW is RoHS compliant and Green (halogen-free) as designated by TI's environmental information guidelines, ensuring that it meets the latest environmental standards for electronic components.
