The SN65HVDA100QDRQ1 is a robust, automotive-grade LIN physical interface transceiver from Texas Instruments, designed to facilitate communication in vehicle networks. This transceiver is compliant with the LIN Bus Specification 2.0, 2.1, and SAE J2602, making it a versatile choice for automotive applications such as body control modules, sensor interfaces, and actuator drives.

Key Features

• Compliance with LIN 2.0, 2.1, and SAE J2602 standards.
• Wide operating voltage range (5V to 27V) for flexible use in automotive environments.
• Exceptional ESD performance of ±15kV on the LIN bus and wakeup pins, ensuring durability and reliability in harsh conditions.
• Integrated slope control to minimize radio frequency interference (RFI).
• Low-current standby mode with remote wakeup capability, making it suitable for power-sensitive applications.
• Thermal shutdown protection for enhanced safety and longevity of the device.
• Robust dominant state timeout function to prevent bus line lockup.

Applications

The SN65HVDA100QDRQ1's robustness and compliance with automotive communication standards make it ideal for a wide range of applications in modern vehicles. These include:

• Body control modules that manage features like power windows, mirrors, and seats.
• Sensor interfaces for temperature, pressure, and other types of environmental and system monitoring.
• Actuator drives for controlling motors and other moving components.
• Automotive comfort and convenience features.
• Engine and transmission control units.

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the SN65HVDA100QDRQ1 is no exception. It is designed to meet the stringent requirements of the automotive industry, ensuring operation under extreme conditions and providing a reliable solution for vehicle network communications.

Package and Availability

The SN65HVDA100QDRQ1 is available in a small-outline integrated circuit package, specifically the 8-pin SOIC (D) package. This compact form factor is suitable for space-constrained applications while providing the necessary connections for easy integration into automotive systems. For purchasing and detailed specifications, customers can visit the Texas Instruments website or contact authorized distributors.
