Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 2.5V
Output Current 5mA
Tolerance ±0.15%
Temperature Coefficient 30ppm/°C
Noise - 0.1Hz to 10Hz 70μVp-p
Voltage - Input 2.7 V to 5.5 V
Operating Supply Current 8.5μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SC-70-3
Win Source Part Number 143648-REF3325AIDCKT
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Portable Devices, Consumer Electronics, Sensing & Instrumentation, Test & Measurement, Medical, Power Management
Ultra Librarian 3D Model Ultra Librarian REF3325AIDCKT CAD Model

Description

The REF3325AIDCKT is a high-performance, low-power voltage reference product from the globally renowned technology company, Texas Instruments.

  • Output Voltage: 2.5V
  • Drift: 3 ppm/°C (maximum) over temperature
  • Dropout Voltage: 180mV
  • Quiescent Current: 4µA
  • Operating Temperature Range: -40°C to +125°C
  • Output Current: 10mA
  • Noise: 30µVp-p/V
