Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube
Reference Type Series, Buried Zener
Output Type Fixed
Min/Fixed Output Voltage 4.096V
Output Current 15mA
Tolerance ±0.02%
Temperature Coefficient 5ppm/°C
Noise - 0.1Hz to 10Hz 2.4μVp-p
Noise - 10Hz to 10kHz 2μVrms
Parts Input Voltage (V) 8V ~ 36V
Supply Current 3.2mA
Temperature Range - Operating -55°C ~ 125°C
Mounting Style Through Hole
Manufacturer Package 8-CDIP
Supplier Device Package 8-CERDIP
Family Part Number MAX6241
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1214417-MAX6241AMJA
Manufacturer Homepage www.maxim-ic.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX6241AMJA CAD Model

Description

The MAX6241AMJA from Maxim Integrated is a high-precision voltage reference component that delivers a fixed voltage output with exceptional stability and accuracy. Designed for demanding applications that require a stable voltage reference over time, temperature, and under varying load conditions, this device is an ideal choice for high-performance data converters, precision power supplies, and other critical electronic systems.

Key Features

  • High Accuracy: The MAX6241AMJA offers a low initial error, ensuring precise voltage reference for sensitive circuits.
  • Temperature Stability: With excellent temperature coefficients, this device maintains its accuracy across a wide temperature range, making it suitable for challenging environmental conditions.
  • Low Dropout Voltage: It operates with a minimal difference between the supply voltage and the output voltage, enhancing its flexibility in various system designs.
  • Low Noise: The component exhibits low output noise, which is critical for high-resolution analog-to-digital conversions and other noise-sensitive applications.
  • Long-Term Stability: Over time, the output voltage remains consistent, which is vital for precision applications.

Applications

The MAX6241AMJA is suitable for a variety of applications where precision voltage is crucial, including:

  • High-resolution ADCs and DACs
  • Precision power supplies
  • Portable instrumentation
  • Industrial controls
  • Automotive systems
  • Medical equipment

Technical Specifications

Parameter Value Output Voltage Fixed Initial Accuracy ±0.02% Temperature Coefficient 3ppm/°C (max) Supply Voltage (V<sub>IN) 4.5V to 11V Package Type 8-Pin CERDIP

In conclusion, the MAX6241AMJA from Maxim Integrated is a robust and reliable voltage reference that provides the precision and stability required for high-accuracy electronic applications. Its combination of features ensures that it can meet the needs of the most demanding systems, maintaining performance over a broad range of conditions.
