Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of I/O 16
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 1mA, 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 24-SSOP
Win Source Part Number 026503-PCF8575DBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name PCF8575DBR
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian PCF8575DBR CAD Model

Description

The PCF8575DBR is a high-quality, advanced technology product from Texas Instruments, a leading global semiconductor company renowned for its innovative and reliable products.

  • Function: 16-bit I/O expander that provides remote I/O expansion for most microcontroller families through the I2C interface serial link.
  • Feature: General-purpose remote I/O expansion via the two-wire bidirectional I2C-bus (serial clock (SCL), serial data (SDA)).
  • Feature: 16-bit quasi-bidirectional input/output (I/O) port (P07..P00, P17..P10), including latched outputs with high current drive capability for directly driving LEDs.
  • Feature: Has an interrupt output, which can be connected to the interrupt logic of the microcontroller.
  • Advantage: Low standby current consumption.
  • Temperature Range: Operates over an ambient temperature range from -40 °C to +85 °C.
  • Package: Available in a small-outline package (SO16) and TSSOP (TSSOP24).
  • Compliance: RoHS compliant.
