Products specifications

Manufacturer Texas Instruments
Packaging Reel
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 7.5V/μs
Gain Bandwidth Product 2.5MHz
Current - Input Bias 5pA
Voltage - Input Offset 5μV
Current - Supply 140μA
Current - Output / Channel 65mA
Voltage - Supply, Single/Dual (±) 4.5V ~ 36V, ±2.25V ~ 18V
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-TSSOP, 8-MSOP
Supplier Device Package 8-VSSOP
Manufacturer Pack Quantity 2,500
MSL Level 2 (1 Year)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809720-OPA2191IDGKR
Ultra Librarian 3D Model Ultra Librarian OPA2191IDGKR CAD Model

Description

The OPA2191IDGKR is a precision operational amplifier (op-amp) developed by Texas Instruments, a leader in semiconductor design and manufacturing. This op-amp is part of the OPAx191 series, which is known for its low offset voltage and low quiescent current, making it an ideal choice for a wide range of applications that require high accuracy and efficiency.

Key Features

  • Low Offset Voltage: The OPA2191IDGKR offers an ultra-low offset voltage of just 25 µV (max), which is critical for applications where precision is paramount.
  • Low Quiescent Current: With a low quiescent current of only 700 µA (typical), this op-amp is suitable for battery-powered and energy-saving devices, as it helps extend the operational lifetime.
  • Wide Supply Range: The device can operate over a wide supply range of 4.5V to 36V, or ±2.25V to ±18V for split supplies, providing flexibility for various circuit designs.
  • High Common-Mode Rejection Ratio (CMRR): With a CMRR of 114 dB (typical), the OPA2191IDGKR ensures excellent performance in environments with common-mode noise.
  • Robust ESD Protection: The op-amp features integrated ESD protection circuits, safeguarding the device from electrostatic discharges.

Applications

The OPA2191IDGKR is versatile and can be used in a multitude of applications, including:

  • Precision instrumentation
  • Data acquisition systems
  • Active filtering
  • Medical equipment
  • Automotive controls
  • Power supply control

Package and Quality

This particular model, the OPA2191IDGKR, comes in an 8-pin VSSOP (DGK) package, which is suitable for space-constrained applications. Texas Instruments is committed to high-quality manufacturing and this product is no exception, adhering to stringent industry standards for reliability and performance.
