Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Win Source Part Number 1213078-MAX3232EIPWRG4
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name MAX3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MAX3232EIPWRG4 CAD Model

Description

Product Overview: MAX3232EIPWRG4 by Texas Instruments

The MAX3232EIPWRG4 is a highly-integrated circuit designed and manufactured by Texas Instruments (TI), known for its reliability and performance in providing bidirectional serial communication. This device conforms to the TIA/EIA-232-F Standards and operates at a higher data rate compared to its predecessors. It is specifically engineered to function in environments where the communication protocol requires voltage levels that adhere to the RS-232 standard.

Key Features

  • Supply Voltage Range: The MAX3232EIPWRG4 operates with a versatile VCC range of 3.0V to 5.5V, making it suitable for a wide array of applications and compatible with many microcontrollers and systems that require different operating voltages.
  • Low-Power Consumption: The device is designed for low-power consumption, drawing as little as 300 µA of supply current, which is beneficial for battery-powered and portable devices.
  • High Data Rate: It supports data rates up to 250 kbps, which ensures efficient and fast data transfer for applications that demand high-speed serial communication.
  • Electrostatic Discharge (ESD) Protection: The MAX3232EIPWRG4 comes with built-in ESD protection up to 15kV, providing robustness against static electricity and enhancing the durability of the product.
  • Integrated Charge Pump: The device includes an onboard charge pump circuit that generates the necessary RS-232 voltage levels from a single VCC supply, eliminating the need for additional power supplies.
  • Small Footprint: Offered in a TSSOP-16 package, it occupies minimal space on a printed circuit board (PCB), which is advantageous for space-constrained applications.

Applications

The MAX3232EIPWRG4 is suitable for a variety of applications where RS-232 communication is essential. It is commonly used in:

  • Portable and battery-powered devices
  • Point-of-sale (POS) terminals
  • Peripherals and computer interfaces
  • Industrial control and automation systems
  • GPS receivers and telemetry equipment

With its robust design and comprehensive features, the MAX3232EIPWRG4 from Texas Instruments is an ideal solution for designers looking to implement RS-232 communication in their systems with minimal power consumption and maximum reliability.
