The LM3409N/NOPB is a versatile and high-performance LED driver IC from Texas Instruments designed to efficiently manage power for high-brightness LEDs. It is a P-channel MOSFET (PFET) switching regulator controller specifically tailored for constant current LED illumination applications.

Key Features

• Wide Input Voltage Range: The device operates from an input voltage range of 4.5V to 35V, making it suitable for a variety of LED lighting applications, including automotive, industrial, and general illumination.
• Constant Current Control: The LM3409N/NOPB provides accurate and adjustable constant current output to ensure uniform brightness and color consistency of LEDs.
• Adjustable Switching Frequency: Users can adjust the switching frequency from 200 kHz to 1 MHz, allowing flexibility in balancing efficiency and component size.
• Thermal Shutdown: The built-in thermal shutdown feature protects the device and the LEDs from overheating, enhancing system reliability.
• Dimming Capability: It supports both analog and Pulse-Width Modulation (PWM) dimming, offering precise control over light output and power consumption.
• No Bootstrap Capacitor Required: The unique architecture of the LM3409N/NOPB eliminates the need for a bootstrap capacitor, simplifying the circuit design.

Applications

• Automotive lighting systems
• Industrial and street lighting
• Portable flashlights and headlamps
• Backlighting for displays and monitors
• Architectural and decorative lighting

The LM3409N/NOPB is offered in an 8-pin PDIP (Plastic Dual-In-Line Package) that is RoHS compliant and Lead-Free (NOPB: No Lead (Pb)). This package is designed for easy integration into a wide range of LED lighting solutions. With its robust feature set and Texas Instruments' reputation for quality, the LM3409N/NOPB is an excellent choice for designers looking to create efficient and reliable LED lighting systems.
