The ISOW7842DWE is a state-of-the-art, high-performance, quad-channel digital isolator from Texas Instruments designed to ensure robust communication and signal transfer in harsh industrial environments. This cutting-edge component is part of the ISOW78xx family, known for its integrated high-efficiency power converter which significantly simplifies the power supply design with isolated power.

Key Features

• Robust Isolation: With reinforced isolation certifications, the ISOW7842DWE provides reliable galvanic isolation up to 5000 VRMS for 1 minute per UL and 4242 VPK per VDE.
• High Data Rates: It supports data rates up to 100 Mbps, making it suitable for high-speed communication protocols.
• Low Power Consumption: The integrated power converter offers high efficiency and low emissions, minimizing power loss and thermal footprint.
• Long Lifespan: Designed with a high isolation barrier life of over 40 years at 1500 Vrms working voltage, ensuring long-term reliability.
• Low Emissions: The device has low radiated and conducted emissions, complying with CISPR 22 Class B limits.

Applications

The ISOW7842DWE is ideal for a variety of applications that require robust isolation, such as:

• Industrial automation
• Motor control systems
• Medical equipment
• Power supplies
• Green energy systems

Package and Quality

Encased in a compact 16-pin SOIC (DWE) package, the ISOW7842DWE offers a small form factor solution without compromising performance. It is characterized for operation over the industrial temperature range of -40°C to +125°C. Texas Instruments' commitment to quality ensures that each device meets stringent standards, providing engineers with a reliable and high-performing isolation solution for their designs.
