ISO7420FED Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 50Mbps
Propagation Delay tpLH / tpHL (Max) 11ns, 11ns
Pulse Width Distortion (Max) 3ns
Rise and Fall Time 1.8ns, 1.7ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002077-ISO7420FED
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO7420FED CAD Model

Description

The ISO7420FED is a high-performance, dual-channel digital isolator product manufactured by Texas Instruments.

  • Channels: Two channels in a forward direction
  • Supply Range: 3.0 V to 5.5 V
  • Operational Temperature Range: Between -40°C to 125°C
  • Isolation Voltage: 2500 Vrms for 1 minute per UL 1577
  • Transient Immunity: 50 kV/μs
  • Power Consumption: Low
  • Quiescent Current: 1.6mA @ 1Mbps
  • Data Rate: Up to 1 Mbps
  • Electromagnetic Compatibility (EMC): Robust
  • Insulation: Reinforced insulation per DIN VDE V 0884-11 (VDE V 0884-11):2017-01
  • Package: 8-pin SOIC package
