ISO7242MDW Real Image ISO7242MDW real image580
Same model may have multiple batches, images only for reference.
ISO7242MDW Real Image ISO7242MDW real image580
ISO7242MDW Real Image ISO7242MDW real image580
Same model may have multiple batches, images only for reference.

ISO7242MDW

Part No ISO7242MDW
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 16SOIC
Datasheet
ISO7242MDW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 23ns, 23ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002072-ISO7242MDW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO7242MDW CAD Model

Description

The ISO7242MDW is a high-performance, quad-channel digital isolator produced by Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Channels: Four channels, two forward and two reverse
  • Data Rate: Up to 150 Mbps
  • Isolation Technology: Texas Instruments' award-winning capacitive isolation technology
  • Isolation Barrier: Up to 2.5kVrms
  • Supply Range: 3V to 5.5V
  • Power Consumption: Low, with a typical current of only 1.5mA per channel @ 1Mbps
  • Package: Compact 16-pin SOIC package
  • Temperature Range: Extended temperature range of -40°C to +125°C
