ISO7241MDW Real Image ISO7241MDW Real Image
Same model may have multiple batches, images only for reference.
ISO7241MDW Real Image ISO7241MDW Real Image
ISO7241MDW Real Image ISO7241MDW Real Image
Same model may have multiple batches, images only for reference.

ISO7241MDW

Part No ISO7241MDW
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 16SOIC
Datasheet
ISO7241MDW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 3/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 23ns, 23ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 082551-ISO7241MDW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Computers & Computer Peripherals, Communications & Networking, Automation & Process Control
Ultra Librarian 3D Model Ultra Librarian ISO7241MDW CAD Model

Description

The ISO7241MDW is a high-performance, quad-channel digital isolator produced by Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Channels: Four isolated channels, two forward and two reverse
  • Data Rate: Up to 25 Mbps
  • Isolation Technology: Texas Instruments' award-winning capacitive isolation technology
  • Isolation Voltage Rating: 4242-V PK
  • Temperature Range: -40 to +125 degrees Celsius
  • Power Consumption: Low
  • Package: Wide-body SOIC package
  • Insulation: Reinforced insulation
  • Output State: Default output state ensures safe operation during power loss
