The ISO3086TDW is a high-performance, isolated RS-485 transceiver module designed by Texas Instruments to facilitate reliable communication in industrial environments. This device ensures robust data transmission over long distances and in noisy conditions, making it an ideal choice for industrial network applications such as factory automation, motor control systems, and grid infrastructure.

Key Features

• Integrated Isolation: With 2500 Vrms of isolation for 1 minute per UL 1577, the ISO3086TDW provides excellent protection against high voltage spikes and common-mode noise, ensuring signal integrity and system safety.
• High-Speed Data Rates: Capable of supporting data rates up to 20 Mbps, this transceiver can easily handle high-speed data transmission required by modern industrial protocols.
• Bus-Pin ESD Protection: Offering an impressive 16 kV HBM ESD protection on the bus pins, the device is well-equipped to withstand electrostatic discharges, enhancing its durability in harsh industrial settings.
• Wide Temperature Range: Operating reliably over an extended industrial temperature range of -40°C to +85°C, the ISO3086TDW is suited for deployment in extreme environmental conditions.
• Fail-Safe Receiver: The device ensures a fail-safe output upon open, short, or idle bus conditions, thus maintaining system integrity during fault states.

Applications

The versatility of the ISO3086TDW makes it a perfect fit for a variety of applications, including:

• Industrial Fieldbus Networks
• Building Automation Systems
• Networked Security Stations
• Automated Teller Machines (ATMs)

Package and Quality

The ISO3086TDW comes in a compact 16-pin SOIC (DW) package, optimizing board space without compromising performance. Texas Instruments' commitment to quality ensures that each device meets stringent standards, offering designers a reliable and efficient solution for their RS-485 communication needs.

For detailed specifications, application notes, and support documentation, visit the Texas Instruments official website or contact your local TI distributor.
