INA219AIDR Texas Instruments INA219AIDR Real Image INA219AIDR label picture INA219AIDR real image136 INA219AIDR real image137 INA219AIDR Real Image1 INA219AIDR Real Image2 INA219AIDR Real Image3
Same model may have multiple batches, images only for reference.
INA219AIDR Texas Instruments INA219AIDR Real Image INA219AIDR label picture INA219AIDR real image136 INA219AIDR real image137 INA219AIDR Real Image1 INA219AIDR Real Image2 INA219AIDR Real Image3
INA219AIDR Texas Instruments INA219AIDR Real Image INA219AIDR label picture INA219AIDR real image136 INA219AIDR real image137 INA219AIDR Real Image1 INA219AIDR Real Image2 INA219AIDR Real Image3
Same model may have multiple batches, images only for reference.

INA219AIDR

Part No INA219AIDR
Manufacturer Texas Instruments
Catalog PMIC - Current Regulation/Management
Description IC CURRENT MONITOR 1% 8SOIC
Datasheet
INA219AIDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Current Monitor
Sensing Method High-Side
Accuracy ±1%
Voltage - Input 0 V to 26 V
Output Current 10mA
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 017295-INA219AIDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Power Management, Maintenance & Repair, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian INA219AIDR CAD Model

Description

The INA219AIDR is a high-quality, high-performance product from Texas Instruments, a renowned and trusted global semiconductor design and manufacturing company.

  • Features: Bi-directional, zero-drift, current/power monitor with an I2C interface.
  • Voltage Range: up to 26V
  • Converter: Internal 12-bit analog-to-digital converter (ADC)
  • Features: Programmable calibration value and conversion times for both the bus voltage and shunt voltage
  • Interface: Standard I2C interface (Up to 3.4MHz)
  • Addressing: Programmable address
  • Package: Small, space-saving SOT-23 package
  • Temperature Range: -40°C to +85°C
