Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Function Current Monitor
Sensing Method High-Side
Accuracy ±3.5%
Parts Input Voltage (V) -16V ~ 80V
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number INA200
Manufacturer Pack Quantity 75
MSL Level 2 (1 Year)
Win Source Part Number 1185793-INA200AID
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian INA200AID CAD Model

Description

Product Overview: INA200AID from Texas Instruments

The INA200AID is a versatile and robust current shunt monitor from Texas Instruments, designed to address a wide range of applications in the field of power management and control systems. This high-quality integrated circuit (IC) is engineered to simplify the process of measuring current through a shunt resistor, providing a reliable and accurate solution for current sensing in both industrial and consumer electronics.

Key Features

  • Precision Current Sensing: The INA200AID offers a high-accuracy current sensing capability, which is essential for the precise control and monitoring of electrical systems.
  • Wide Input Common-Mode Range: This device is capable of operating over a wide input common-mode range of -16V to +80V, making it suitable for various applications, including those subject to large voltage swings.
  • Adjustable Overcurrent Threshold: Users can set an overcurrent threshold via an external resistor, which allows for custom current limit settings tailored to specific needs.
  • Open-Drain Alert Pin: The INA200AID features an open-drain alert pin that provides a simple interface for overcurrent detection, simplifying the design of protection circuits.
  • Low Quiescent Current: With a low quiescent current, this device ensures minimal power consumption when operational, enhancing the overall efficiency of the application.

Applications

  • Battery chargers
  • Power management systems
  • Overcurrent protection circuits
  • Automotive and telecommunication systems
  • Portable and handheld devices

The INA200AID is housed in a small, surface-mount package, making it an excellent choice for space-constrained applications. Its ease of use, combined with its high level of integration, provides a compact and effective solution for current sensing tasks. Whether it's for battery management, load detection, or power supply monitoring, the INA200AID from Texas Instruments stands out as a reliable component that can enhance the performance and safety of electronic systems.

Overall, the INA200AID is a testament to Texas Instruments' commitment to providing innovative, high-quality products that meet the evolving needs of the electronics industry.
