Introducing the DS90UB953ATRHBRQ1 from Texas Instruments

The DS90UB953ATRHBRQ1 is a powerful and versatile serializer from Texas Instruments, designed to meet the needs of advanced automotive and industrial camera applications. This integrated circuit is part of Texas Instruments' FPD-Link III family, which is renowned for its ability to transmit high-speed data and power over a single coaxial or twisted-pair cable.

Robust and Reliable Data Transmission

The DS90UB953ATRHBRQ1 facilitates reliable data transmission at high speeds, with support for up to 100 MHz forward channel bandwidth. This allows for the transfer of high-resolution and high-frame-rate video data with low latency, making it an ideal solution for safety-critical applications such as automotive driver assistance systems (ADAS).

Advanced Features for Enhanced Performance

Equipped with an array of advanced features, the DS90UB953ATRHBRQ1 includes adaptive equalization, which enables it to compensate for cable losses and ensure signal integrity over long cable runs. Additionally, the device supports a wide range of data formats, including 12-, 14-, and 16-bit linear or combined HDR data, providing flexibility in camera design and image processing.

Designed for Harsh Environments

The DS90UB953ATRHBRQ1 is designed to withstand the harsh conditions commonly found in automotive and industrial environments. It operates over an extended temperature range and is qualified for automotive applications, adhering to the stringent AEC-Q100 Grade 2 standard.

Seamless Integration and Simplified Design

With its compact size and minimal external component requirements, the DS90UB953ATRHBRQ1 streamlines the design process, allowing for easier integration into existing systems. The device also features I2C-based device control options, which simplifies system configuration and management.

Key Specifications:

• FPD-Link III Serializer
• Supports up to 100 MHz high-speed forward channel
• Adaptive equalization for cable loss compensation
• Extended temperature range for automotive applications
• Compliant with AEC-Q100 Grade 2 standard
• Supports 12-, 14-, and 16-bit linear or combined HDR data formats

Whether you're designing a sophisticated automotive camera system or a rugged industrial imaging application, the DS90UB953ATRHBRQ1 from Texas Instruments offers the performance, reliability, and ease of use required to deliver superior results.
