The DS280BR810ZBFR is a high-performance, low-power, 8-channel repeater with integrated signal conditioning and retimer functionality. Designed and manufactured by Texas Instruments, this advanced IC is engineered to enhance signal integrity for high-speed interconnects. It is an ideal solution for applications that demand robust data transmission over long and potentially noisy cables and backplanes.

Key Features

• High-Speed Performance: Supports data rates up to 28 Gbps per channel, making it suitable for demanding applications such as 100G Ethernet, EDR InfiniBand, and 32G Fibre Channel.
• Adaptive Equalization: Integrated continuous-time linear equalization (CTLE), decision feedback equalization (DFE), and feed-forward equalization (FFE) provide superior signal conditioning to compensate for channel loss and inter-symbol interference (ISI).
• Flexible Configuration: The device can be configured via an I2C interface or pin strapping, allowing for easy adaptation to specific system requirements.
• Low Power Consumption: Optimized for energy efficiency, the DS280BR810ZBFR consumes minimal power, reducing the thermal footprint and enabling greener solutions.
• Jitter Cleaning: The onboard clock and data recovery (CDR) circuits clean jitter from the data stream, ensuring high-fidelity signal transmission.
• Robust Design: Built to handle harsh environments, the device operates over an extended temperature range and includes advanced diagnostics for system monitoring and troubleshooting.

Applications

The DS280BR810ZBFR is versatile and can be used in a variety of high-speed data communication applications, including:

• Data center and enterprise networking equipment
• High-performance computing (HPC) systems
• Storage area networks (SAN)
• Telecommunications infrastructure

Package and Quality

This device is offered in a compact 8 mm x 8 mm, 65-pin BGA (Ball Grid Array) package, which is suitable for space-constrained applications. As with all Texas Instruments products, the DS280BR810ZBFR is manufactured to the highest quality standards, ensuring reliability and performance in the most demanding environments.
