DS90LV804TSQ Real Image DS90LV804TSQ real image3713 DS90LV804TSQ real image3714 DS90LV804TSQ Real Image
Same model may have multiple batches, images only for reference.
DS90LV804TSQ Real Image DS90LV804TSQ real image3713 DS90LV804TSQ real image3714 DS90LV804TSQ Real Image
DS90LV804TSQ Real Image DS90LV804TSQ real image3713 DS90LV804TSQ real image3714 DS90LV804TSQ Real Image
Same model may have multiple batches, images only for reference.

DS90LV804TSQ

Part No DS90LV804TSQ
Manufacturer Texas Instruments
Catalog Interface - Signal Buffers, Repeaters, Splitters
Description IC REDRIVER LVDS 4CH 32WQFN
Datasheet
DS90LV804TSQ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Buffer, ReDriver
Applications LVDS
Input CML, LVDS, LVPECL
Output LVDS
Data Rate (Max) 800Mbps
Number of Channels 4
Delay Time 2.0ns
Capacitance - Input 3.5pF
Supply Voltage - Operating 3.15 V to 3.45 V
Operating Supply Current 117mA
Temperature Range - Operating -40°C to 85°C
Case / Package 32-WQFN (5x5)
Win Source Part Number 083439-DS90LV804TSQ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian DS90LV804TSQ CAD Model

Description

Overview

The DS90LV804TSQ is a versatile LVDS buffer/repeater with quad-channel operations, designed to bolster signal integrity over long cable runs or extended data paths.

  • Applications:
    • Broadcast Video Equipment
    • High-Speed Networking
    • Data Center Infrastructure

Features

  • Quad-channel support
  • High signal integrity retention
  • Low propagation delay

Benefits

  • Ensures minimal signal degradation over distance
  • Reduced power consumption for efficient operation
  • Flexible use in various data-heavy environments

Additional Details

The DS90LV804TSQ is designed for superior performance in environments where maintaining high-quality signal integrity is essential, offering flexibility and reliability.
