Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Applications General Purpose
Output Current 1.1A
Supply Voltage - Operating 8.2 V to 45 V
Voltage - Load 8.2 V to 45 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 28-HTSSOP
Win Source Part Number 014627-DRV8802PWPR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DRV8802PWPR CAD Model

Description

DRV8802PWPR Motor Driver IC

With the ability to control two DC motors, the DRV8802PWPR is an excellent choice for dual motor applications. It combines reliability with ease of use, suitable for both amateur and professional projects.

Features and Benefits

  • Dual Motor Control: Drives two independent DC motors with up to 2 A per channel.
  • Versatile Voltage Range: Operates between 8 V and 36 V, suitable for a wide range of applications.
  • Protective Measures: Incorporates thermal shutdown, overcurrent protection, and undervoltage lockout.
  • Efficient Packaging: Provided in a 28-pin HTSSOP package, conserving board space.

Applications

  • Dual-Drive Robotics
  • Automated Blinds and Window Shutters
  • Conveyor Control Systems
  • Vending Machines
