Product Overview: Texas Instruments DRV8402DKDR Motor Driver

The DRV8402DKDR from Texas Instruments is a highly integrated motor driver designed to efficiently control brushless DC (BLDC) motors, brushed DC motors, and stepper motors. It is part of Texas Instruments' robust DRV8x motor driver series, which is renowned for its performance, reliability, and ease of use. This particular model is optimized for high-performance applications requiring precise control of motor speed and position.

Key Features

• Integrated Dual H-Bridge: The DRV8402DKDR features dual H-bridge drivers capable of driving two DC motors or one stepper motor, providing bidirectional control with high efficiency.
• High Output Current: It can deliver up to 3.5A of continuous output current per channel, with peak currents up to 6A, making it suitable for a wide range of motor sizes.
• Advanced Protection Features: This motor driver includes overcurrent protection, thermal shutdown, undervoltage lockout, and cross-conduction protection, ensuring the safety and longevity of the motor and the driver itself.
• Flexible Power Supply: The device operates from a supply voltage range of 8.2V to 60V, accommodating various applications and motor types.
• Programmable Current Regulation: Users can program the current limit through an external resistor, which allows for fine-tuning to match specific motor requirements.
• PH/EN Interface: The DRV8402DKDR supports a simple PH/EN (Phase/Enable) interface for easy control and direction changes of the motor.

Applications

The versatility of the DRV8402DKDR makes it a prime choice for a multitude of applications, including but not limited to:

• Office Automation Machines
• Power Tools
• Industrial Equipment
• Robotics
• Home Appliances

Package and Quality

The DRV8402DKDR comes in a HTSSOP (High Temperature Thin Shrink Small Outline Package) with PowerPAD™ for enhanced thermal performance. It is RoHS compliant and designed to meet the rigorous standards of industrial performance. With its advanced features and reliable operation, the DRV8402DKDR motor driver is an excellent choice for designers looking to enhance their motor control systems.
