Product Overview: Texas Instruments CDCLVC1104PW

The CDCLVC1104PW is a high-performance, low-voltage clock buffer from Texas Instruments. This device is designed to distribute one clock input to four output clocks with minimal skew and low additive phase noise, making it an ideal solution for clock distribution in a wide range of digital applications.

Built for precision and reliability, the CDCLVC1104PW operates over a wide supply voltage range of 1.6V to 3.6V. This flexibility allows it to be used in various systems without the need for additional level shifting, simplifying design and reducing overall system complexity.

The device features a maximum output frequency of 200 MHz and is characterized for operation from -40°C to 85°C, ensuring stable performance across diverse environmental conditions. The low additive jitter and high-frequency capability make it a perfect choice for applications requiring a clean and stable clock signal.

Packaged in a 14-pin TSSOP (Thin Shrink Small Outline Package), the CDCLVC1104PW is designed with space-saving in mind, making it suitable for compact PCB layouts. Its small form factor is particularly beneficial for dense circuit boards where real estate is at a premium.

Whether it's for telecommunications, computing, or industrial applications, the CDCLVC1104PW provides the reliability and performance expected from a Texas Instruments product. Its ease of use, coupled with support documentation and design resources available from Texas Instruments, ensures a smooth integration into your design workflow.

In summary, the CDCLVC1104PW is a versatile and efficient solution for your clock distribution needs. Its robust design, combined with Texas Instruments' quality and support, make it an excellent choice for designers looking to optimize their systems' timing architecture with precision and dependability.
