CD74HC4053M Real Image CD74HC4053M Real Image
Same model may have multiple batches, images only for reference.
CD74HC4053M Real Image CD74HC4053M Real Image
CD74HC4053M Real Image CD74HC4053M Real Image
Same model may have multiple batches, images only for reference.

CD74HC4053M

Part No CD74HC4053M
Manufacturer Texas Instruments
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MUX/DEMUX TRIPLE 2X1 16SOIC
Datasheet
CD74HC4053M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Switch Circuit SPDT
Number of Circuits 3
Max On Resistance 130 Ohm
Channel-to-Channel Matching (ΔRon) 5 Ohm
Single Supply Voltage (V+) 2 V to 6 V
Dual Supply Voltage(V±) ±1 V to 5 V
-3db Bandwidth 200MHz
Channel Capacitance(CS off, CD off) 8pF
Max Leakage Current (IS off) 100nA
Temperature Range - Operating -55°C to 125°C (TA)
Case / Package 16-SOIC
Win Source Part Number 083162-CD74HC4053M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CD74HC4053M CAD Model

Description

Description and Applications

The CD74HC4053M, tailored for high-speed and low-power applications, acts as a triple 2-channel multiplexer/demultiplexer, catering to signal multiplexing tasks in computing and industrial applications.

Features and Benefits

  • Supply voltage flexibility: 2V to 6V
  • ON resistance: <52? at 5V
  • Minimal charge injection
  • High tolerance for signal frequency changes
  • Optimized for low power operation

Additional Details

Ideal for a streamlined signal routing process, the device offers minimal power dissipation and a design that supports both high-density and speed-sensitive applications with precision.
