Product Overview: CD74ACT273PWR from Texas Instruments

The CD74ACT273PWR is a high-performance, CMOS Octal D-Type Flip-Flop with a clear feature, designed and manufactured by Texas Instruments. This integrated circuit is part of the ACT family, which is well-known for its higher speed yet lower power consumption compared to other logic families. The device is specifically designed to operate with a 5V power supply, making it suitable for interfacing with microprocessors and other logic devices that operate at this voltage level.

Key Features

• Logic Type: Octal D-Type Flip-Flop with Clear
• Operating Voltage: 4.5V to 5.5V, typically designed for 5V systems
• IC Package Type: TSSOP (Thin Shrink Small Outline Package)
• Pin Count: 20 pins, providing ample connections for interfacing
• Propagation Delay: Fast speed with typical propagation delay significantly lower than other logic families
• Output Current: Capable of sourcing or sinking 24mA, providing robust drive capabilities

Applications

The CD74ACT273PWR is highly versatile and can be used in a variety of applications where data storage or signal synchronization is required. Common applications include:

• Buffer/Storage Registers
• System Control Registers
• Parity Generators/Checkers
• Shift Registers

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the CD74ACT273PWR is no exception. It is designed to meet or exceed the stringent requirements of the industrial and commercial markets. The device is available in a TSSOP package, which is both space-saving and ensures reliable operation over a wide range of temperatures.

Ordering and Packaging

The CD74ACT273PWR comes in tape and reel packaging, which facilitates automated assembly processes and is ideal for large volume production requirements. For prototyping or small volume requirements, the device is also available in tube packaging.

For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments datasheet for the CD74ACT273PWR.
