CC2520RHDT

Part No CC2520RHDT
Manufacturer Texas Instruments
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU 802.15.4 28-VFQFN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type TxRx + MCU
RF Family/Standard 802.15.4
Protocol Zigbee
Modulation DSSS, O-QPSK
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 5dBm
Sensitivity -98dBm
Memory Size 768B RAM
Serial Interfaces SPI
GPIO 6
Supply Voltage - Operating 1.8 V to 3.8 V
Current - Receiving 18.5mA to 22.3mA
Current - Transmitting 25.8mA to 33.6mA
Temperature Range - Operating -40°C to 125°C
Dimension 28-VFQFN Exposed Pad
Win Source Part Number 012768-CC2520RHDT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CC2520RHDT CAD Model

Description

CC2520RHDT Zigbee RF Transceiver

The CC2520RHDT, engineered by Texas Instruments, is a 2.4 GHz Zigbee RF transceiver offering robust performance and low power usage perfect for IoT devices.

  • Features & Benefits:
  • Complies with IEEE 802.15.4 standards for Zigbee networks.
  • Enhanced sensitivity for reliable communication.
  • Integrated AES-128 security encryption.

Applications/Projects:

  • Home Automation Systems
  • Environmental Monitoring
  • Wireless Sensor Networks
  • IoT Device Integration

Additional Details: Offers a seamless integration with existing Zigbee networks, providing versatility for a range of smart applications.
