The Texas Instruments ADS1278SHKP is a high-performance, multichannel analog-to-digital converter (ADC) that offers exceptional dynamic range and accuracy. Designed for applications requiring high-resolution signal acquisition, this ADC is an ideal choice for industrial data acquisition systems, medical instrumentation, seismic data acquisition, and other high-precision applications.

Key Features

• High Resolution: The ADS1278SHKP features a 24-bit delta-sigma ADC architecture, providing outstanding noise performance and a high dynamic range that ensures accurate signal representation.
• Multi-Channel Design: With eight simultaneously-sampling input channels, this device is capable of handling multiple signal inputs, reducing the need for additional components and simplifying system design.
• High Data Rate: It offers a maximum data rate of 105k samples per second per channel, enabling the capture of fast transient signals without compromising data integrity.
• Programmable Gain: The programmable gain amplifier (PGA) allows for gain settings from 1 to 128, making it versatile for various input signal ranges.
• Integrated Features: The ADS1278SHKP includes an onboard oscillator, reference, and buffer, which minimizes external component requirements and simplifies circuit design.
• Digital Filter: It incorporates a digital filter that helps to reduce noise and improve signal quality, which is critical for high-precision measurements.
• Interface: The device supports SPI-compatible serial interface, allowing easy integration with most microcontrollers and digital systems.

Applications

• Industrial Data Acquisition Systems
• Medical Instrumentation
• Seismic Data Acquisition
• Test and Measurement Equipment

The ADS1278SHKP from Texas Instruments is packaged in a compact HTQFP-64 package, making it suitable for space-constrained applications. Its robust design and wide operating temperature range ensure reliable performance even in harsh environments. With its combination of high precision, multiple channels, and ease of use, the ADS1278SHKP stands out as a top-tier solution for demanding data acquisition tasks.
