Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Texas Instruments
Series 78SR100
Packaging Tray
Part Status Obsolete(EOL)
Type Non-Isolated PoL Module
Number of Outputs 1
Input Voltage MIN 14.5V
Voltage Input MAX 30V
Voltage - Output 1 5.25V
Current - Output (Maximum) 1.5A
Applications ITE (Commercial)
Features OTP, SCP
Operating Temperature Range -40°C ~ 85°C
Mounting Through Hole, Right Angle
Package 3-SIP Module
Size 0.94" L x 0.90" W x 0.31" H (23.9mm x 22.9mm x 7.9mm)
Win Source Part Number 1133740-78SR153HC
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name 78SR153
Introduction Date February 01, 2006
Country of Origin United States of America
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian 78SR153HC CAD Model

Description

The 78SR153HC is a highly efficient, non-isolated, step-down regulator from the reputable electronics manufacturer, Texas Instruments. This component is part of the 78SR series, known for their reliability and performance in converting higher voltages to lower voltages without the need for a heat sink. The 78SR153HC is designed to deliver a fixed output voltage with a high level of accuracy, making it an ideal choice for a wide range of applications.

Key Features

  • Output Voltage: The 78SR153HC provides a fixed output voltage of 3.3V, which is a common requirement for many digital circuits and low-power applications.
  • Output Current: Capable of delivering up to 1.5A of continuous output current, this regulator can power a variety of components without the need for additional cooling measures.
  • High Efficiency: With an efficiency rate that can reach up to 95%, this regulator ensures minimal power loss during voltage conversion, thereby reducing the overall energy consumption of the system.
  • Wide Input Voltage Range: The device can operate with an input voltage range from 4.5V to 18V, allowing for flexibility in various power supply configurations.
  • Thermal Protection: The 78SR153HC is equipped with thermal shutdown and current limit features to protect the device and the system from excessive heat and overcurrent conditions.
  • Compact Size: Housed in a compact package, the regulator is suitable for space-constrained applications.
  • Easy Integration: The pin-out is compatible with older 3-terminal linear regulators, facilitating easy upgrades in existing designs.

Applications

The 78SR153HC is versatile and can be used in a variety of applications, including:

  • Point-of-load conversions in distributed power systems
  • Embedded systems and microcontroller power supplies
  • Industrial control and automation
  • Portable and battery-operated devices

With its robust design and high efficiency, the 78SR153HC from Texas Instruments is a reliable choice for engineers and designers seeking a high-performance voltage regulator for their electronic projects.
