Same model may have multiple batches, images only for reference.
PT371024 Real Image
Same model may have multiple batches, images only for reference.

PT371024

Part No PT371024
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series PT, SCHRACK
Package Bulk
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form 3PDT (3 Form C)
Contact Rating (Current) 10 A
Switching Voltage 400VAC - Max
Coil Current 31 mA
Coil Type Non Latching
Features Mechanical Indicator, Test Button
Termination Style PC Pin
Must Operate Voltage 18 VDC
Must Release Voltage 2.4 VDC
Operate Time 15 ms
Release Time 10 ms
Temperature Range - Operating -40°C ~ 70°C
Contact Material Silver Nickel (AgNi)
Relay Type General Purpose
Coil Resistance 777 Ohms
Base Product Number PT371
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0050
Win Source Part Number 1315546-PT371024
Ultra Librarian 3D Model Ultra Librarian PT371024 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays PT371024 is a 3PDT (3 Form C) power relay designed for use in applications where a mechanical indicator and test button are required.

  • Coil Voltage: 24VDC
  • Coil Resistance: 777 ohms
  • Coil Current: 31mA
  • Operating Temperature: -40°C to 70°C
  • Contact Rating (Current): 10A
  • Switching Voltage: 400VAC - Max
  • MSL Level: 1 (Unlimited)
  • Manufacturer: TE Connectivity Potter & Brumfield Relays
