MPE206N Real Image
Same model may have multiple batches, images only for reference.

MPE206N

Part No MPE206N
Manufacturer TE Connectivity
Catalog Pushbutton Switches
Description SWITCH PUSHBUTTON DPDT 6A 125V / Pushbutton Switch DPDT Standard Panel Mount, Rear
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Pushbutton Switches
Mfr TE Connectivity ALCOSWITCH Switches
Series MPE
Package Bulk
Product Status Obsolete
Mounting Type Panel Mount, Rear
Type Standard
Circuit DPDT
Switch Function On-On
Current Rating (Amps) 6A (AC), 4A (DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 28 V
Actuator Type Plunger for Cap
Actuator Marking No Marking
Termination Style Solder Lug
Ingress Protection Splash Proof
Panel Cutout Dimensions Circular - 6.35mm Dia
Temperature Range - Operating -20°C ~ 80°C
Electrical Life 50,000 Cycles
Base Product Number MPE206
MSL Level Not Applicable
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.50.9035
Other Names 414375674,-MPE206N-SI,450-1072,-4-1437567-4-SI-ND,4-1437567-4,-4-1437567-4-SI
Standard Package 100
Win Source Part Number 1084489-MPE206N
Ultra Librarian 3D Model Ultra Librarian MPE206N CAD Model

Description

The 1084489-MPE206N is a pushbutton switch manufactured by TE Connectivity.

  • Circuit: DPDT
  • Switch Function: On-On
  • Actuator Type: Plunger for cap
  • Panel Cutout Dimensions: Circular - 6.35mm Dia.
  • Voltage Rating: 125VAC and 28VDC
  • Termination: Solder lug terminated
  • Ingress Protection: Splash-proof
  • Standard Package: 100
  • Temperature Range: -20°C to 80°C
  • Electrical Life: 50,000 cycles
  • Current Rating: 6A (AC), 4A (DC)
  • Mounting: Panel-mounted and rear-mounted
