292161-2 Real Image
Same model may have multiple batches, images only for reference.

292161-2

Part No 292161-2
Manufacturer TE Connectivity
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 2POS 2MM  /  Connector Header Through Hole 2 position 0.079" (2.00mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series CT
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.079" (2.00mm)
Number of Positions 2
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 3 Wall
Mounting Type Through Hole
Termination Kinked Pin, Solder
Fastening Type Detent Lock
Contact Length - Mating 0.177" (4.50mm)
Contact Length - Post 0.126" (3.20mm)
Overall Contact Length 0.370" (9.40mm)
Insulation Height 0.268" (6.80mm)
Contact Shape Circular
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA66), Nylon 6/6
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 125VAC
Applications General Purpose
Base Product Number 292161
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2921612,-292161-2-SI,-292161-2-CSI,2266-292161-2,A98588
Standard Package 1,000
Win Source Part Number 1125837-292161-2
Ultra Librarian 3D Model Ultra Librarian 292161-2 CAD Model

Description

The TE Connectivity AMP Connectors 292161-2 is a rectangular connector that is ideal for use in a variety of electronic applications.

  • Connector Type: Header
  • Standard Package: 1,000
  • Win Source Part Number: 1125837-292161-2
  • Category: Rectangular Connectors - Headers, Male Pins
  • RoHS Compliant: Yes
