PXD2024S12 Real Image
Same model may have multiple batches, images only for reference.

PXD2024S12

Part No PXD2024S12
Manufacturer TDK-Lambda Americas Inc.
Catalog Board Mount Modules
Description DC-DC Converters, Power module type, Output: 20W, 12V, Isolated type
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Case / Package Module
Current - Output 1 1.67 A
Depth 25.4 mm
Efficiency 87 %
Features OCP, OVP, SCP
Height 10.16 mm
Isolation Isolated
Isolation Voltage 1.6 kV
Length 50.8 mm
Max Input Voltage 36 V
Max Operating Temperature 100 °C
Max Output Current 1.67 A
Max Power Dissipation 20 W
Min Input Voltage 18 V
Mount Through Hole
Number of Outputs 1
Number of Pins 6
Operating Supply Voltage 24 V
Output Current 1.67 A
Output Power 20 W
Output Voltage 12 V
Power Rating 20 W
Radiation Hardening No
RoHS Compliant
Schedule B 8504409510
Voltage - Output 1 12 V
Width 25.4 mm
Win Source Part Number 1179492-PXD2024S12
Categories Board Mount Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PXD2024S12 CAD Model

Description

The TDK-Lambda Americas Inc. PXD2024S12 is an isolated board mount module with a power rating of 20 W and output voltage of 12 V.

  • Features: OCP, OVP, and SCP
  • Efficiency: 87%
  • Length: 50.8 mm
  • Height: 10.16 mm
  • Width: 25.4 mm
  • Number of Pins: 6
  • Input Voltage: 24 V
  • Supply and Demand Status: Limited
  • RoHS: Compliant
  • Win Source Part Number: 1179492-PXD2024S12
