Same model may have multiple batches, images only for reference.
MGFW154805 Real Image
Same model may have multiple batches, images only for reference.

MGFW154805

Part No MGFW154805
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-5V / Isolated Module DC DC Converter 2 Output 5V or 10V -5V 1.5A, 1.5A 18V - 76V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr Cosel USA, Inc.
Series MGFW (15W)
Package Box
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 18V
Voltage - Input (Max) 76V
Voltage - Output 1 5V or 10V
Voltage - Output 2 -5V
Current - Output (Max) 1.5A, 1.5A
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Bridgeable, Remote On/Off, OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 84%
Mounting Type Through Hole
Package / Case 6-DIP Module
Dimension 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
Other Names 1776-1356
Standard Package 1
Win Source Part Number 1210553-MGFW154805
Ultra Librarian 3D Model Ultra Librarian MGFW154805 CAD Model

Description

The MGFW154805 is a 15W isolated module DC-DC converter from Cosel USA, Inc..

  • Features: Remote On/Off, Over Current Protection
  • Applications: ITE (Commercial)
  • Mounting Type: Through Hole
  • Package / Case: Box
  • Voltage - Isolation: 1.5 kV
  • Number of Outputs: 2
  • Voltage - Output 1: 5V or 10V
  • Voltage - Output 2: -5V
  • Current - Output 1: 1.5A
  • Current - Output 2: -1.5A
  • Voltage - Input: 18V ~ 76V
  • Efficiency: 84 %
  • Operating Temperature: -40°C ~ 85°C (With Derating)
  • Size / Dimension: 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
  • HTSUS: 8504.40.9580
