Same model may have multiple batches, images only for reference.
PH75S110-15 Real Image
Same model may have multiple batches, images only for reference.

PH75S110-15

Part No PH75S110-15
Manufacturer TDK-Lambda Americas Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 15V 75W / Isolated Module DC DC Converter 1 Output 15V 5A 82V - 185V Input
Datasheet
PH75S110-15 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr TDK-Lambda Americas Inc
Series PH-S (75W)
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 82V
Voltage - Input (Max) 185V
Voltage - Output 1 15V
Current - Output (Max) 5A
Power (Watts) 75 W
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP, OVP
Temperature Range - Operating -20°C ~ 85°C
Mounting Type Through Hole
Package / Case Module
Dimension 3.85" L x 1.61" W x 0.50" H (86.0mm x 41.0mm x 12.7mm)
Control Features Enable, Active Low
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Names PH75S11015,Q3611558
Standard Package 1
Win Source Part Number 1084699-PH75S110-15
Ultra Librarian 3D Model Ultra Librarian PH75S110-15 CAD Model

Description

The PH75S110-15 is a 75W isolated module DC-DC converter from TDK-Lambda Americas Inc.

  • Voltage Isolation: 3kV
  • Current Output: 5A
  • Voltage Input: 82V to 185V
  • Output Voltage: 15V
  • Features: Remote on/off, overcurrent protection (OCP), and overvoltage protection (OVP) control features
  • Mounting: Through-hole mountable
  • Dimension: 3.85” L x 1.61” W x 0.50” H (86.0mm x 41.0mm x 12.7mm)
  • Application: Suitable for use in ITE (commercial) applications
  • Temperature Range: -20°C to 85°C
  • Status: Obsolete
  • Alternative Parts: PH50S110-15, PH75S48-12, UEI30-150-Q48N-C, UEI-15/3.3-Q12P-C, UEI15-033-Q48P-CPH75S-110-15, and PH75S11015
