KMS40-5

Part No KMS40-5
Manufacturer TDK-Lambda Americas Inc.
Catalog Board Mount AC DC Converters
Description AC/DC CONVERTER 5V 40W / Enclosed AC DC Converters 1 Output 5V 8A 90 ~ 264 VAC, 100 ~ 375 VDC Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>AC DC Converters
Mfr TDK-Lambda Americas Inc
Series KM (40W)
Package Bulk
Product Status Not For New Designs
Type Enclosed
Number of Outputs 1
Voltage - Input 90 ~ 264 VAC, 100 ~ 375 VDC
Voltage - Output 1 5V
Current - Output (Max) 8A
Power (Watts) 40 W
Applications Medical
Features Universal Input
Temperature Range - Operating -25°C ~ 70°C (With Derating)
Efficiency 79%
Mounting Type Through Hole
Package / Case 7-DIP Module, 5 Leads
Dimension 3.50" L x 2.50" W x 1.06" H (89.0mm x 63.5mm x 27.0mm)
Approval Agency CE, EN, IEC, UL
Standard Number 60601-1; 60950-1; 62368-1
Line Regulation 0.5%
Load Regulation 1%
Weight 0.618 lb (280.32 g)
Base Product Number KMS40
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9510
Other Names KMS405,285-1767
Standard Package 1
Win Source Part Number 1024659-KMS40-5
Ultra Librarian 3D Model Ultra Librarian KMS40-5 CAD Model

Description

The KMS40-5 is an enclosed AC/DC converter from TDK-Lambda Americas Inc. It is a single output converter with a 5V output at 8A. The input voltage range is 90-264VAC or 100-375VDC. The KMS40-5 has an efficiency of up to 90% and an operating temperature range of -40 to +70°C. It measures 2.17 x 1.65 x 0.83 inches and weighs 2.1 ounces.

The KMS40-5 is a versatile and reliable power supply that is suitable for a wide range of applications. It is commonly used in industrial, medical, and telecommunications equipment. It is also a popular choice for portable and battery-powered devices.

Here are some of the key features of the KMS40-5:

  • Wide input voltage range: 90-264VAC or 100-375VDC
  • High efficiency: up to 90%
  • Wide operating temperature range: -40 to +70°C
  • Small size: 2.17 x 1.65 x 0.83 inches
  • Lightweight: 2.1 ounces
  • Enclosed design for protection from dust and moisture
  • UL/CSA/TUV/CE safety approvals

The KMS40-5 is a well-designed and reliable power supply that is backed by a three-year warranty. It is a good choice for a wide range of applications, including:

  • Industrial automation
  • Medical devices
  • Telecommunications equipment
  • Portable and battery-powered devices
  • Test and measurement equipment
  • Consumer electronics

If you are looking for a versatile and reliable power supply, the KMS40-5 is a good option to consider. It is backed by a reputable manufacturer and has a three-year warranty.
