ICG-20330 TDK Corporation ICG-20330 real image23256
Same model may have multiple batches, images only for reference.
ICG-20330 TDK Corporation ICG-20330 real image23256
ICG-20330 TDK Corporation ICG-20330 real image23256
Same model may have multiple batches, images only for reference.

ICG-20330

Part No ICG-20330
Manufacturer TDK InvenSense
Catalog Motion Sensors - Gyroscopes
Description HIGH PERFORMANCE 3-AXIS OIS/EIS
Datasheet
ICG-20330 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Motion Sensors - Gyroscopes
Mfr TDK InvenSense
Package Tape & Reel
Product Status Obsolete
Type Digital
Axis X (Pitch), Y (Roll), Z (Yaw)
Range °/s ±31.25, 62.5, 125, 250
Sensitivity (LSB/(°/s)) 131 ~ 1048
Bandwidth 1.6kHz
Output Type I2C, SPI
Voltage - Supply 1.71V ~ 3.45V
Current - Supply 2.9 mA
Features Adjustable Bandwidth, Selectable Scale, Sleep Mode, Temperature Sensor
Temperature Range - Operating -40°C ~ 85°C
Standard Package 5,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
HTSUS 0000.00.0000
Win Source Part Number 825411-ICG-20330
Ultra Librarian 3D Model Ultra Librarian ICG-20330 CAD Model

Description

The 825411-ICG-20330 is a digital gyroscope designed for motion sensing applications.

  • Features: Adjustable bandwidth, selectable scale, sleep mode, temperature sensor
  • Output Type: I2C and SPI
  • Bandwidth: 1.6kHz
  • Current Supply: 2.9 mA
  • Manufacturer: TDK InvenSense
  • Status: Obsolete

It features adjustable bandwidth, selectable scale, sleep mode, and a temperature sensor, providing versatility in various use cases. The output type of this gyroscope is I2C and SPI, allowing for easy data communication. With a bandwidth of 1.6kHz, it can capture precise motion data. The compact size and low current supply of 2.9 mA make it suitable for power-constrained applications. This product is supplied by TDK InvenSense and is currently obsolete in the market.
