Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Color Red, Yellow
Configuration Common Cathode
Lens Color White
Lens Transparency Diffused
Millicandela Rating 15mcd Red, 19mcd Yellow
Lens Style Round with Domed Top
Lens Size 3mm, T-1
Voltage - Forward (Vf) (Typ) 2V Red, 2.1V Yellow
Current - Test 20mA Red, 20mA Yellow
Viewing Angle 60°
Mounting Type Through Hole
Wavelength - Dominant 617nm Red, 588nm Yellow
Wavelength - Peak 627nm Red, 590nm Yellow
Case / Package Radial - 3 Lead, Formed
Supplier Device Package T-1 (3mm)
Height (Max) 5.00mm
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1572846-XLUYR34M
Ultra Librarian 3D Model Ultra Librarian XLUYR34M CAD Model
