The STPS30M100DJF-TR is a high-performance Power Schottky Rectifier designed by STMicroelectronics, renowned for its expertise in semiconductor solutions. This rectifier is specifically engineered to meet the demands of high efficiency and reliability in a wide range of applications, including switch-mode power supplies, converters, freewheeling diodes, reverse battery protection, and other power management tasks.

Key Features

• High Junction Temperature Capability: The STPS30M100DJF-TR is capable of operating at high temperatures, which ensures stability and reliability in demanding situations.
• Low Forward Voltage Drop: With a low forward voltage drop, this rectifier enhances system efficiency by minimizing power losses during operation.
• High Surge Current Capability: This component can handle high surge currents, making it an ideal choice for applications that experience transient over-current conditions.
• Dual Center Tap Configuration: The dual center tap configuration allows for flexibility in circuit designs, providing options for different application layouts.

Electrical Characteristics

• Average forward current: 30 A
• Repetitive peak reverse voltage: 100 V
• Non-repetitive peak forward surge current: 300 A
• Forward voltage drop: 0.77 V at 15 A
• Operating junction temperature range: -40°C to 175°C

Package and Quality

The STPS30M100DJF-TR is delivered in a TO-220AB package, which is widely used and recognized for its robustness and excellent thermal performance. This package is suitable for through-hole mounting, which is beneficial for applications requiring strong mechanical anchoring to the PCB.

STMicroelectronics is committed to delivering high-quality products. The STPS30M100DJF-TR rectifier is manufactured with adherence to strict industry standards, ensuring reliable performance and longevity in the field.

Applications

Due to its robust design and electrical characteristics, the STPS30M100DJF-TR is suitable for a variety of applications, including:

• Power supply units for consumer electronics
• Industrial power systems
• Telecommunication equipment
• Automotive applications
• Renewable energy systems

With the STPS30M100DJF-TR, designers and engineers can achieve efficient and reliable power conversion in their electronic designs, ensuring optimal performance and energy savings.
