The STM32100B-EVAL evaluation board from STMicroelectronics provides an ideal platform for evaluating the capabilities and features of the STM32F100RB high-performance microcontroller. This evaluation board is specifically designed to help developers and engineers to explore the functionalities and to develop and share applications that utilize the STM32F100RB MCU’s full potential.

Key Features

• STM32F100RB microcontroller with 128 KB of Flash memory and 8 KB of RAM.
• Comprehensive range of hardware features that enable the evaluation of all peripherals (USB, CAN, USART, etc.) and the development of user-specific applications.
• Embedded ST-LINK/V2 for MCU programming and debugging, with the option to be used as a standalone debugger for other boards.
• Multiple power supply options including USB, external or internal sources.
• Audio DAC with integrated class D speaker driver.
• Two I2C compatible EEPROMs, one with a 64-Kbit and the other with a 256-Kbit capacity.
• MicroSD card slot for storage expansion.
• Graphical LCD with touch screen for interactive user interface designs.
• Extension connectors for daughterboard or wrapping board for further expansion.
• Four 5 V power supply options: power jack, USB connector, daughterboard, or extension connector.

Benefits

The STM32100B-EVAL is designed to support a wide array of applications, ranging from industrial control systems to medical devices. Its rich set of peripherals and expansion options make it a versatile tool for rapid prototyping and development. The inclusion of an embedded ST-LINK/V2 debugger simplifies the development process, allowing for easy programming and real-time debugging without the need for additional hardware.

Applications

With its robust design and comprehensive feature set, the STM32100B-EVAL board is suitable for a wide range of applications, including:

• Industrial automation and control.
• Medical equipment and healthcare devices.
• Consumer electronics.
• Home appliances.
• Automotive applications.
• Complex embedded systems requiring a rich user interface.

The STM32100B-EVAL evaluation board is an essential tool for engineers looking to harness the power of the STM32 microcontroller in their next project, providing a flexible and feature-rich environment for innovation and development.
