STMicroelectronics M24C32-WMN6TP EEPROM

The M24C32-WMN6TP is a 32-Kbit serial EEPROM (Electrically Erasable Programmable Read-Only Memory) device from STMicroelectronics, designed to provide a robust and efficient memory storage solution for a wide range of applications. This integrated circuit features a standard I²C-compatible (two-wire) serial interface, enabling easy integration into existing designs and facilitating communication with microcontrollers and processors.

Key Features

• Memory Size: 32 Kbits (4 Kbytes) of EEPROM memory, organized as 4,096 x 8 bits, which is ideal for storing configurations, settings, or small amounts of data that must be preserved during power cycles.
• Write Cycle Time: Fast write cycle times of 5 ms (typical) allow for quick data updates and minimal system downtime during write operations.
• Operating Voltage Range: The device operates over a wide voltage range of 2.5 V to 5.5 V, making it suitable for various power environments and ensuring compatibility with both 3.3 V and 5 V systems.
• Data Retention: Guaranteed data retention of 40 years and endurance of 1 million write cycles per byte, ensuring long-term reliability of the stored information.
• Package: The M24C32-WMN6TP comes in a compact SO-8 (Small Outline Package) form factor, which is ideal for space-constrained applications.

Applications

This EEPROM device is versatile and can be used in various applications, such as:

• Consumer electronics (e.g., TVs, radios, and home appliances)
• Industrial control systems
• Medical devices
• Automotive systems
• Telecommunication equipment

Product Advantages

The M24C32-WMN6TP is designed with the needs of modern electronics in mind, offering advantages such as low-power consumption, which is critical for battery-operated devices, and a wide operating temperature range of -40°C to +85°C, ensuring performance under harsh conditions. Additionally, the device supports byte and page write, enabling flexible programming options for developers.

With its robust feature set, the M24C32-WMN6TP from STMicroelectronics is an excellent choice for designers looking for a reliable and flexible non-volatile memory solution.
