Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 17V
Peak Pulse Current(Ippm) 5A (8/20μs)
Power Dissipation - Pd 80W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 0.85pF @ 1MHz
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 015087-DVIULC6-4SC6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Consumer Electronics, Communications & Networking, Test & Measurement, Medical
Family Name DVIULC6
Introduction Date June 02, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian DVIULC6-4SC6 CAD Model

Description

The DVIULC6-4SC6 is a state-of-the-art Transient Voltage Suppression (TVS) diode designed by STMicroelectronics, specifically engineered to protect sensitive electronic equipment from voltage transients induced by electrostatic discharge (ESD) and other voltage spikes. This device is characterized by its low capacitance, making it particularly suitable for high-speed data line applications where signal integrity is paramount.

Key Features

  • Low Capacitance: The ultra-low capacitance of the DVIULC6-4SC6, typically just 3 pF, ensures that high-speed signals are not significantly distorted, preserving the integrity of the data transmission.
  • High ESD Protection: This device offers robust protection against ESD, exceeding the IEC 61000-4-2 standard (±30 kV air, ±30 kV contact discharge), safeguarding sensitive components from sudden electrical surges.
  • Low Leakage Current: With its low leakage current, the DVIULC6-4SC6 ensures minimal power loss, making it an energy-efficient solution for modern electronic systems.
  • High Surge Capability: The diode can withstand high surge currents, providing reliable protection against transient voltage spikes that could potentially damage the system.
  • Compact Package: Housed in an SOT-23-6L package, the DVIULC6-4SC6 is designed for space-constrained applications, offering a compact footprint without compromising on performance.

Applications

The DVIULC6-4SC6 is ideal for protecting a wide range of high-speed data lines, including USB 2.0, Ethernet, video lines, and other multimedia applications. Its low capacitance and high protection level make it particularly well-suited for sensitive communication interfaces and portable devices where space and power efficiency are critical.

Reliability and Quality

STMicroelectronics is renowned for its commitment to quality and reliability. The DVIULC6-4SC6 is no exception, manufactured to the highest standards to ensure consistent performance and durability across a broad range of operating conditions. It is a trusted solution for designers looking to enhance the resilience of their electronic systems against the challenges posed by ESD and other transient voltage events.
