Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Thyristors - SCRs
Mfr Solid State Inc.
Series 2N5206
Package Box
Product Status Active
Voltage - Off State 1 kV
Voltage - Gate Trigger (Vgt) (Max) 3 V
Current - Gate Trigger (Igt) (Max) 40 mA
Voltage - On State (Vtm) (Max) 2.3 V
Current - On State (It (RMS)) (Max) 35 A
Current - Hold (Ih) (Max) 100 mA
Current - Off State (Max) 2 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 300A
SCR Type Standard Recovery
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Stud Mount
Package / Case TO-208AA, TO-48-3, Stud
Supplier Device Package TO-48
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 541251-2N5206
Ultra Librarian 3D Model Ultra Librarian 2N5206 CAD Model

Description

The 541251-2N5206 is a standard recovery silicon-controlled rectifier (SCR) that is commonly used in electronic circuits.

  • Type: Silicon-Controlled Rectifier (SCR)
  • Voltage Rating: 1kV
  • Current Rating: 35A
  • Gate Trigger Voltage (Vgt): 3V
  • Gate Trigger Current (Igt): 40 mA
  • Package: TO-208AA, TO-48-3, Stud
  • Manufacturer: Solid State Inc.
  • Status: Active
  • Standard Package: 10 pcs
  • Suitable for: Applications that require high-power switching, such as motor control, power supplies, and lighting control.
