ST-3-56 Real Image
Same model may have multiple batches, images only for reference.

ST-3-56

Part No ST-3-56
Manufacturer Signal Transformer
Catalog Power Transformers
Description PWR XFMR LAMINATED 2.4VA TH /
Datasheet
ST-3-56 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Power Transformers
Mfr Signal Transformer
Series ST
Package Bulk
Type Laminated Core
Voltage - Primary 115V
Voltage - Secondary (Full Load) Parallel 28V, Series 56V
Current - Output (Max) Parallel 90mA, Series 45mA
Primary Winding(s) Single
Secondary Winding(s) Dual
Center Tap No
Power - Max 2.4VA
Mounting Type Through Hole
Termination Style PC Pin
Dimension 34.90mm L x 28.60mm W
Height - Seated (Max) 30.80mm
Voltage - Isolation 2500Vrms
Weight 0.25 lb (113.4 g)
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Standard Package 100
Win Source Part Number 1165161-ST-3-56
Ultra Librarian 3D Model Ultra Librarian ST-3-56 CAD Model

Description

This laminated core transformer, part number 1165161-ST-3-56, is a power transformer that falls under the category of transformers.

  • Termination Style: PC Pin
  • Package: Bulk
  • Height: 30.80mm
  • Weight: 0.25 lb
  • Voltage Isolation: 2500Vrms
  • Voltage Primary: 115V
  • Current Output: Parallel 90mA and series 45mA
  • Voltage Secondary: Parallel 28V and series 56V
  • Primary Windings: Single
  • Secondary Windings: Dual
  • Mounting: Through Hole
  • Dimension: 34.90mm L x 28.60mm W
  • Alternative Part: ST3-56
  • ECCN: EAR99
