The 2SC1507 is an NPN silicon transistor. Savantic, Inc. likely rebrands or distributes this part, which was originally manufactured by a different semiconductor company (potentially Toshiba). These transistors are generally used for audio amplification and switching applications.

Applications

• Audio Amplifiers
• Switching Regulators
• General-Purpose Amplification
• Driver Stages
• Voltage Regulators

Features

• NPN Silicon Transistor
• High Current Gain (hFE)
• Low Saturation Voltage
• High Collector-Emitter Voltage

Benefits

• Provides good amplification in audio circuits.
• Offers efficient switching performance.
• Suitable for driving larger loads.
• Can handle relatively high voltages.

Technical Specifications

The 2SC1507 typically features a collector-emitter voltage (VCEO) of 60V, a collector-base voltage (VCBO) of 70V, and an emitter-base voltage (VEBO) of 6V. It has a collector current (IC) of 1A and a collector power dissipation (PC) of 800mW. Its current gain (hFE) typically ranges from 100 to 400. Transition Frequency (fT) is around 120 MHz. It operates within a temperature range of -55°C to +150°C. Package type is TO-92.
