IPBT-102-H1-T-D-GP Samtec Inc.
Same model may have multiple batches, images only for reference.

IPBT-102-H1-T-D-GP

Part No IPBT-102-H1-T-D-GP
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Description CONN HEADER VERT 4POS 4.20MM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Samtec Inc.
Packaging Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.165" (4.20mm)
Number of Positions 4
Number of Rows 2
Row Spacing - Mating 0.165" (4.20mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Style Through Hole
Termination Solder
Fastening Type Locking Ramp
Contact Length - Mating 0.260" (6.60mm)
Contact Length - Post 0.130" (3.30mm)
Overall Contact Length 0.510" (12.95mm)
Insulation Height 0.380" (9.65mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Features Mating Flange
Temperature Range - Operating -55°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Voltage Rating 400VAC, 565VDC
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 814008-IPBT-102-H1-T-D-GP
Ultra Librarian 3D Model Ultra Librarian IPBT-102-H1-T-D-GP CAD Model

Description

The Samtec Inc. 814008-IPBT-102-H1-T-D-GP is a board-to-board or cable connector with a 4.20mm pitch mating and a square contact shape.

  • Pitch Mating: 4.20mm
  • Contact Shape: Square
  • Connector Type: Header Connector
  • Contact Type: Male Pin
  • Fastening Type: Locking Ramp
  • Contact Material: Copper Alloy
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Temperature Range: -55°C to 105°C
  • Current Rating: - amps
  • Supply and Demand Status: Limited
  • Manufacturer Pack Quantity: 1
