Products specifications Report Issue?

Manufacturer Rohm Semiconductor
Win Source Part Number 1124735-2SB1010
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 2SB1010 CAD Model

Description

The 2SB1010 is a silicon PNP epitaxial planar transistor manufactured by Rohm Semiconductor. It is designed for high-current switching and amplifier applications. This transistor is commonly used in power supplies, motor control circuits, and audio amplifiers due to its high current handling capability and low saturation voltage.

Applications:

  • Power supplies: Used in switching regulators and DC-DC converters.
  • Motor control circuits: Employed in motor drivers for controlling the speed and direction of motors.
  • Audio amplifiers: Used in output stages of audio amplifiers for driving speakers.
  • Switching circuits: Used as a high-current switch for controlling various loads.
  • General-purpose amplification: Can be used in various amplifier circuits.

Features:

  • High current capability: Handles high collector current.
  • Low saturation voltage: Minimizes power loss in saturation.
  • High power dissipation: Can dissipate a significant amount of power.
  • Fast switching speed: Allows for efficient switching operation.
  • Complementary NPN transistor available: Can be used in complementary circuits.

Benefits:

  • Efficient power handling: High current capability and low saturation voltage improve efficiency.
  • Versatile applications: Suitable for a wide range of power switching and amplifier applications.
  • Reliable performance: Ensures stable operation over a wide range of operating conditions.
  • Easy to use: Simple to implement in various circuit designs.
  • Cost-effective solution: Provides a cost-effective solution for high-current applications.

Additional Details:

The 2SB1010 transistor requires proper heat sinking to dissipate heat generated during operation. It should be operated within its specified voltage and current ratings. The transistor is typically available in a TO-220 or similar package.
