TLC59731D Real Image TLC59731D real image17130 TLC59731D Real Image1 TLC59731D Real Image2
Same model may have multiple batches, images only for reference.
TLC59731D Real Image TLC59731D real image17130 TLC59731D Real Image1 TLC59731D Real Image2
TLC59731D Real Image TLC59731D real image17130 TLC59731D Real Image1 TLC59731D Real Image2
Same model may have multiple batches, images only for reference.

TLC59731D

Part No TLC59731D
Manufacturer Rochester Electronics
Catalog PMIC - LED Drivers
Description TLC59731 3-CHANNEL, 8-BIT, PWM L
Datasheet
TLC59731D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Features LED Driver IC 3 Output Linear Shift Register - Dimming 50mA 8-SOIC
Manufacturer Texas Instruments
Series EasySet™
Package Bulk
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting Surface Mount
Package 8-SOIC (0.154", 3.90mm Width)
Case / Package 8-SOIC
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Quantity per package 1
Popularity High
Supply and Demand Status Balance
Win Source Part Number 899857-TLC59731D
Ultra Librarian 3D Model Ultra Librarian TLC59731D CAD Model

Description

The Texas Instruments TLC59731D is a versatile LED driver IC that comes with 3 output linear shift registers. This IC is designed to operate in a temperature range of -40°C to 85°C and is available in an 8-SOIC package.

  • Manufacturer: Texas Instruments
  • Type: LED Driver IC
  • Outputs: 3 Output Linear Shift Registers
  • Operating Temperature: -40°C to 85°C
  • Package: 8-SOIC
  • Features: Dimming Functionality
  • Current: Up to 50mA
  • Series: EasySet™
