Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Active
Frequency 50MHz to 4GHz
P1dB 22.7dB
Gain 12.9dB
Noise Figure 0.8dB
RF Type Cellular, ISM, PCS
Supply Voltage - Operating 3 V to 5 V
Operating Supply Current 46mA
Test Frequency 1.9GHz
Case / Package SOT-343
Win Source Part Number 030753-SPF5043Z
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SPF-5043
Introduction Date August 25, 2006
ECCN 5A991.g
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SPF5043Z CAD Model

Description

The SPF5043Z is a high-popularity RF amplifier manufactured by RF Micro Devices.

  • Category: RF/IF and RFID
  • Supply and demand status: balanced
  • Gain: 12.9dB
  • Noise Figure: 0.8dB
  • P1dB: 22.7dB
