SGL-0163Z RF Micro Devices SGL-0163Z real image5355
Same model may have multiple batches, images only for reference.
SGL-0163Z RF Micro Devices SGL-0163Z real image5355
SGL-0163Z RF Micro Devices SGL-0163Z real image5355
Same model may have multiple batches, images only for reference.

SGL-0163Z

Part No SGL-0163Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description RF Amp Single Cascadable Amp 1.3GHz 5V 6-Pin SOT-363 T/R / IC AMP HBT SIGE 1300MHZ SOT-363
Datasheet
SGL-0163Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 100MHz to 1.3GHz
P1dB 5.6dBm (3.6mW)
Gain 14dB to 17dB
Noise Figure 1.2dB to 1.7dB
RF Type GPS, RFiD
Supply Voltage - Operating 2.5 V to 4 V
Operating Supply Current 9.5mA to 14mA
Test Frequency 900MHz
Case / Package SOT-363
Win Source Part Number 064355-SGL-0163Z
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SGL-0163
Introduction Date September 15, 2005
ECCN 5A991.g
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SGL-0163Z CAD Model

Description

The SGL-0163Z is an obsolete RF Micro Devices component used for GPS and RFiD applications.

  • Supply and Demand Status: Limited
  • Packaging: Reel-TR
  • Test Frequency: 900MHz
  • Frequency Range: 100MHz to 1.3GHz
  • Gain: 14dB to 17dB
  • Noise Figure: 1.2dB to 1.7dB
  • P1dB: 5.6dBm (3.6mW)
  • Category: RF/IF and RFID
  • Operating Voltage Range: 2.5 V to 4 V
  • Operating Supply Current: 9.5mA to 14mA
  • Alternative Parts: MSA-0286-TR2, MSA-0286-TR1, A4012, and MSA-0286-TR1MCG
  • Introduction Date: September 15, 2005
  • Estimated EOL Date: Obsolete/End of Life
  • ECCN Code: 5A991.g
