Same model may have multiple batches, images only for reference.
RF2422 Real Image
Same model may have multiple batches, images only for reference.

RF2422

Part No RF2422
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF)
Description CONN SMA PLUG STR 50 OHM SOLDER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Bulk
Status Active
Connector Style SMA
Connector Type Plug, Male Pin
Contact Termination Solder
Shield Termination Solder
Impedance 50 Ohm
Mounting Free Hanging (In-Line)
Cable Group RG-405 (.085", .086" Semi Rigid)
Fastening Type Threaded
Maximum Input Frequency 18GHz
Housing Color Gold, Silver
Ingress Protection Weatherproof
Includes 3 pcs - 1 Connector, 1 Contact, 1 Insulator
Body Material Stainless Steel
Body Finish Gold; Passivated
Center Contact Plating Gold
Dielectric Material Polytetrafluoroethylene (PTFE)
Temperature Range - Operating -65°C to 165°C
Center Contact Material Beryllium Copper
Mating Cycles 500
Win Source Part Number 293369-RF2422
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2422 CAD Model

Description

The Amphenol RF Division RF2422 is a weatherproof SMA plug male pin connector.

  • Fastening Type: threaded
  • Contact Termination: solder
  • Material: stainless steel
  • Housing Color: gold and silver
  • Impedance: 50 Ohm
  • Temperature Range: -65°C to 165°C
  • Cable Group: RG-405 (.085", .086" Semi Rigid)
  • Maximum Input Frequency: 18GHz
  • Mating Cycle: 500
  • Comes With: 3 pcs - 1 Connector, 1 Contact, 1 Insulator
  • Status: active
