UPD78F0513AGB-GAF-AX Renesas Electronics America
Same model may have multiple batches, images only for reference.

UPD78F0513AGB-GAF-AX

Part No UPD78F0513AGB-GAF-AX
Manufacturer Renesas Electronics America
Catalog Embedded - Microcontrollers
Description 8-Bit Single-Chip Microcontrollers
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Renesas Electronics America
Series 78K0/Kx2
Packaging Tray
Core Processor 78K/0
Core Size 8-Bit
Speed 20MHz
Connectivity 3-Wire SIO, I2C, LIN, UART/USART
Peripherals LVD, POR, PWM, WDT
Number of I/O 37
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
RAM Size 1K x 8
Supply Voltage 1.8 V ~ 5.5 V
Data Converters A/D 8x10b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Package 44-LQFP
Win Source Part Number 1277955-UPD78F0513AGB-GAF-AX
Manufacturer Homepage www.renesas.com
Popularity Medium
Supply and Demand Status Limited
Quantity per package 160
Family Name uPD78F0513
Introduction Date July 28, 2005
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian UPD78F0513AGB-GAF-AX CAD Model

Description

The Renesas Electronics America UPD78F0513AGB-GAF-AX is a microcontroller unit manufactured by Renesas Electronics America.

  • Series: 78K0/Kx2
  • Speed: 20MHz
  • Program Memory Size: 32KB
  • Suitable for: Wide range of applications
  • Win Source Part Number: 1277955
