RTL8111H-CGT Product Description

The RTL8111H-CGT is a high-performance Gigabit Ethernet controller from Realtek Semiconductor Corp. It is designed for use in a wide range of networking applications, including desktop PCs, laptops, servers, and embedded systems.

The RTL8111H-CGT supports the PCI Express 1.1 bus interface for host communications with power management, and is compliant with the IEEE 802.3u specification for 10/100Mbps Ethernet and the IEEE 802.3ab specification for 1000Mbps Ethernet.

The RTL8111H-CGT features a number of advanced features, including:

• Support for jumbo frames up to 9KB
• Support for Wake-on-LAN and Wake-on-Magic Packet
• Support for IEEE 802.1Q VLAN tagging
• Support for IEEE 802.1x authentication
• Support for IEEE 802.3az Energy Efficient Ethernet
• Support for IPv4 and IPv6 checksum offloading

The RTL8111H-CGT is available in a QFN32 package and is RoHS compliant.

Applications

The RTL8111H-CGT is suitable for a wide range of networking applications, including:

• Desktop PCs
• Laptops
• Servers
• Embedded systems
• Routers
• Switches
• Access points
• Network storage devices
• Industrial automation equipment

Features and Benefits

The RTL8111H-CGT offers a number of features and benefits, including:

• High performance: The RTL8111H-CGT supports Gigabit Ethernet speeds, making it ideal for demanding applications such as streaming video and gaming.
• Low power consumption: The RTL8111H-CGT features a number of power-saving features, making it ideal for mobile and embedded devices.
• Feature-rich: The RTL8111H-CGT supports a wide range of advanced features, including jumbo frames, VLAN tagging, and Wake-on-LAN.
• Cost-effective: The RTL8111H-CGT is a cost-effective solution for adding Gigabit Ethernet connectivity to a wide range of devices.

Conclusion

The RTL8111H-CGT is a high-performance, low-power Gigabit Ethernet controller that is suitable for a wide range of networking applications. It offers a number of advanced features and is a cost-effective solution for adding Gigabit Ethernet connectivity to devices.
